ENGLISH
Jandy
®
, JXi
™
Gas-Fired Pool & Spa Heater
|
Installation & Operation Manual
Section 8. Optional Remote Controls
The JXi heater controls can be wired for remote
operation. All Zodiac
®
AquaLink
®
Control Systems will
permit the heater to be operated by remote control. The
instructions in the following sections should be used as a
general guideline only. Please follow the instructions that
accompany your selected control system thoroughly.
If you are setting up a new pool or spa system, or if you
have any questions about your heater control system,
please call Jandy technical support at 800.822.7933.
Electrical wiring must be in accordance with the latest
edition of the National Electrical Code (NEC), ANSI
®
/
National Fire Protection Association
®
(NFPA70
®
), unless
local code requirements indicate otherwise.
Refer to Figure 16 for a complete diagram of wiring
connections and terminals.
Consult with Jandy Technical Support, 800.822.7933 for
questions about installing non-Zodiac remote controls.
8.1 Connecting to a Remote Pool-Off-Spa Selector (3-Wire Connection)
• Turn off the power to both the pool/spa control
system and the heater unit.
• Follow service access instructions from Section 6.1.
• Run the wires from the pool/spa control system
through the low voltage knockout on the right or left
hand side of the heater.
• Connect the wiring from the pool/spa control system to the
heater remote control terminal. See Figure 16 item “b”.
• Connect the three wires to the Spa, Pool & Common
terminals of the J6 terminal bar.
• Reinstall front panel.
• Restore power to the heater and the
pool/spa control system.
8.1.1 Congure the Control Panel:
• Make sure the pool heater is OFF.
• Press and hold MENU, then the POOL and SPA
buttons for 5 seconds to access Service Setup mode.
NOTE: The display will revert back to OFF 1 minute after the last key press.
• Press Up or Down to display REMOTE.
• Press MENU, REMOTE OFF (default) is displayed.
• Use Up or Down to scroll through the Remote
options until HI-LO-COM is displayed, then press
MENU to select.
• Press POOL or SPA to exit Service Setup mode.
8.2 Connecting to an AquaLink® Control System or Remote TSTAT (2-Wire Connection)
An interrupt (on/off-type) remote can be connected as
a Remote TSTAT to turn the heater on or off but not
perform any other function. When using this type of
connection, remember to set the heater control to “pool”
or “SPA” and set the thermostat control to maximum.
8.2.1 Install the Remote TSTAT:
• Turn off the power to both the pool/spa control
system and the heater unit.
• Follow service access instructions from Section 6.1.
• Run the wires from the pool/spa control system
through the low voltage knockout on the right or left
hand side of the heater.
• Connect the wiring from the pool/spa control system
to the heater remote control terminal.
• Connect the two wires to Pool and Common (not
Spa) on the J6 terminal bar. See Figure 16 item “b”.
• Reinstall panel.
• Restore power to the heater and the pool/spa
control system.
NOTE: Ifyouinstallatimeclocktocontrolthelterpumpoperation,itisrecommendedthatthetimeclockhaveitsownlowvoltage(Fireman’s)switch
toturnofftheheaterbeforeturningoffthepump.Theswitchshouldshutofftheheaterabout15minutesbeforethelterpumpshutsoff.Thiswillallow
foramoreefcientoperationbyremovinganyresidualheatcontainedintheheatexchangerbacktothepool.
CAUTION
To avoid damage to the heater, do not connect the power supply of the heater to the output side of the clock if your time clock simply
interrupts the high voltage power supply or has a high voltage output. Doing so will prevent the blower from purging the residual heat from the
heater when the heater turns off. The blower must be allowed to run for 45 seconds after the heater shuts off.
