Page 34
Key Model Order
No Description No Part No.
ELECTRICAL SYSTEM
19 Temperature Control Assembly All R0058200
20 Wire Harness All R0058000
21 Plate Assembly All 10457300
22 On-Off Switch All R0099800
23 Temperature Control Label All H0105300
24 Temperature Sensor All R0011800
25 Protector Sleeve, Bulb All 10444900
26 "O" Ring, Temperature Control Bulb All E0116400
27 Thermostat Knob, Black All R0010700
28 Stop Plate, "Temp-Lok" All 10583100
29 Temperature Control Gasket All S0070000
30 Bezel All S0069800
31 Stop Plate Screw (Not Shown) All F0033300
32 Temperature Sensor Retainer Bracket All 10447300
33 Retainer Bracket Screw All F0009100
34 Pressure Switch & Siphon Loop Assembly (2 PSI)All R0097600
35 Pressure Switch, 2 PSI All R0013200
35 Pressure Switch, 1 PSI All R0011300
35 Pressure Switch, 1-10 PSI All R0015500
36 Siphon Loop Assembly All R0057800
37 High-Limit Switch Assembly All R0023200
38 High-Limit Switch, 135° F All R0022700
39 High-Limit Switch, 150° F All R0023000
40 High-Limit Switch Retainer Boot All S0098900
41 High-Limit Switch Wire Harness All 10419300
42 High-Limit Switch Retainer Clip All 10418400
43 High-Limit Switch Cover All 10418300
44 Fusible Link Assembly All R0012200
45 Fusible Link Bracket All 10479900
46 Terminal Block All R0097800
VENT SYSTEM
47 Top Enclosure 125-400 R0343401-05
48 Top Filler Plate 125-400 R0343701-05
49 Rainshield Kit 125-400 R0318301-05
50 Flue Collector Assembly 125-400 R0316401-05
51 Outdoor Vent Cap 125-400 10561501-05
52 Indoor Drafthood 125-400 10561401-05
53 Flue Transition Plate 125-400 10861901-05
54 Adapter Plate 125-400 10535301-05
55 Clip All 10211000
56 Flue Collector Hold Down Clamp All 10726000
WATER SYSTEM
57 Inlet/Outlet Header, 2" All R0056400
57 Inlet/Outlet Header, Bronze, 2" All R0016800
58 Return Header (Includes set of 9 gaskets) All R0058300
58 Return Header, Bronze
(Includes set of 9 gaskets) All R0054600
59 Header Bolt Assembly (Set of 8) All R0057000
60 Bolt for Headers, 2 1/2" All F0046100
61 Washer for Headers All F0011100
62 Nut for Headers All F0003100
63 Header Gasket Assembly (Set of 18) All R0050800
64 Flange & Gasket Assembly (Set of 2 ) All R0055000
65 Flange, 2" All 10573500
66 Flange Gasket, 2" All S0078000
67 Flange Sleeve, 2" All S0078200
68 Flange Bolt All F0031700
69 Flange Gasket, 1 1/2 - 2" All S0078100
70 Rubber Grommet for Drain Plug All R0316300
71 Grommet, Slitted (Not Shown) All S0071100
72 Brass Connector Body All P0019701
73 Brass Drain Plug 1/4" All P0026800
74 Brass Plug, 3/4" All P0027000
75 By-Pass Assembly w/o spring (Iron Cap) All R0013100
75 By-Pass Assembly with spring (Bronze Cap) 125-400 10701401-05
76 By-Pass Valve Rod All S0079800
Key Model Order
No Description No Part No.
SECTION 11.
Replacement Parts
11.1 Ordering Information
To order or purchase parts for the Lite2 model LG
pool/spa heater, contact your nearest Jandy dealer or
distributor. See the Jandy web page at www.Jandy.com
for the nearest service center. If they cannot supply you
with what you need, contact the Customer Service
Manager at Water Pik Technologies, P.O. Box 6000,
Petaluma, California, 94954, Telephone (707) 776-
8200 extension 245.
NOTE: To supply the correct part it is important
that you state the model number, serial number
and type of gas when applicable. This
information is on the rating plate inside the
heater.
11.2 Parts List
The following three pages contain a parts list,
general exploded view and detailed exploded views to
aid in parts identification. Please refer to these pages
when ordering parts for your Lite2 pool/spa heater.
PILOT/IGNITER SYSTEM
1 Pilot, Main Burner Assembly, NAT All R0099100
1 Pilot, Main Burner Assembly, LPG All R0099200
2 Pilot Burner, NAT All R0096700
2 Pilot Burner, LPG All R0096600
3 Pilot Electrode All W0040000
4 Pilot Generator All W0036901
5 Ceramic Insulator Assembly All 10418820
6 Burner, Main w/Pilot Bracket All 10457500
7 High Voltage Lead Assembly All R0099000
8 Pilot Tubing All R0037000
9 Piezo Lighter Assembly All R0096800
10 Pilot Condensate Shield All R0323300
MAIN GAS ASSEMBLY
11 Burner Tray Assy, NAT 125-400 R0098601-05
11 Burner Tray Assy, LPG 125-400 R0098701-05
12 Burner Tray, Shelf Only 125-400 R0317001-05
13 Gas Valve, NAT All R0096400
13 Gas Valve, LPG All R0096900
14 Gas Orifice, NAT 0 - 3,000 ft alt. (EA.) (Note 1) All L0032200
14 Gas Orifice, LPG 0 - 5,000 ft alt. (EA.) (Note 2) All L0032900
15 Anti-Rotation Bracket All 10835900
16 Mounting Bracket Assembly All 10419200
17 Burner, Main All L0052300
18 Burner Manifold 125 L0052200
18 Burner Manifold 175 L0006300
18 Burner Manifold 250 L0006400
18 Burner Manifold 325 L0006500
18 Burner Manifold 400 L0006600
