105
UMG 512-PRO
15.4 Temperature measurement input
Temperature measurement input
3-wire measurement
Update time 1 second
Connectible sensors PT100, PT1000, KTY83, KTY84
Total load (sensor and cable) max. 4 kOhms
Line length Up to 30m (32.81yd) unshielded;
greater than 30m (32.81yd) shielded
Sensor
type
Temperature range Resistance range Measurement uncer-
tainty
KTY83 -55°C (-67 °F) ... +175°C (347°F) 500ohms ... 2.6 kOhms ±1.5% rng
KTY84 -40°C (-40°F) ... +300°C (572°F) 350ohms ... 2.6 kOhms ±1.5% rng
PT100 -99°C (-146°F) ... +500°C (932°F) 60ohms ... 180ohms ±1.5% rng
PT1000 -99°C (-146°F) ... +500°C (932°F) 600ohms ... 1.8kOhms ±1.5% rng
Terminal connection capacity (temperature measurement input)
Connectible conductors. Only connect one conductor per terminal point!
Single core, multi-core, fine-stranded 0.2 - 1.5mm
2
, AWG 28-16
Wire ferrules (non-insulated) 0.2 - 1.5mm
2
, AWG 26-16
Wire ferrules (insulated) 0.2 - 1.5mm
2
, AWG 26-16
Tightening torque 0.2 - 0.25Nm (1.77 - 2.21 lbfin)
Strip length 7mm (0.2756in)
Potential isolation and electrical safety of the temperature measurement inputs
· The temperature measurement input is double insulated relative to the current and voltage measure-
ment inputs as well as to the supply voltage.
· There is no insulation relative to the RCM measurement input.
· There is only functional isolation relative to the Ethernet, Profibus, RS-485 and digital I/O interfaces.
· The external temperature sensor must be double insulated relative to system components with dan-
gerous contact voltage (according to IEC61010-1:2010).
