54
Sewing Light
The sewing light is located behind the face plate.
To change the bulb, take the face plate off the sewing
machine by removing the setscrew.
* Unplug the power supply before changing the bulb.
* Do not dismantle the machine other than explained in
thismanual.
(A) To remove: Turn to the left.
To replace: Turn to the right.
(B) To remove: Push and twist to the left.
To replace: Push and twist to the right.
Warning:
The bulb may be HOT. Protect your fingers when handle it.
Oil the Machine
Caution:
Turn off the power switch and/or unplug the machine
before oil the machine.
Oil the points as shown at least once a year.
Use good quality sewing machine oil.
One or two drops of oil is sufficient.
Remove excess oil, otherwise it may stain fabric.
In case machine is not used for an extended time, oil it before
sewing.
Oil behind the face plate
Remove the screw and face plate.
Oil the point as indicated in the illustration.
Screw
Face plate
Oil behind the shuttle hook area
Open the hook cover.
Remove the hook race ring and hook.
Oil the point as indicated in the illustration.
Hook cover
Hook race ring
Hook
(A)
(B)
1
2
3
4
5
1
2
3
4
5
