SECTION 1. ESSENTIAL PARTS
Name of Parts
q Direct pattern selection keys
w Mode selecting key
e Down (–) key
r Up (+) key
t LED display
y Spool holder (large)
u Spool pin
i Bobbin winding thread guide
o Thread guide
!0 Thread take-up lever
!1 Thread tension dial
!2 Face plate
!3 Thread cutter
!4 Automatic needle threader
!5 Needle plate
!6 Extension table (Accessory box)
!7 Hook cover
!8 Hook cover release button
!9 Stitch balance adjusting dial
@0 Reverse stitch button
@1 Auto-lock button
@2 Needle Up/Down button
@3 Needle clamp screw
@4 Needle
@5 Presser foot
@6 Foot holder
@7 Carrying handle
@8 Bobbin winding spindle
@9 Bobbin winder stopper
#0 Handwheel
#1 Power switch
#2 Machine socket
#3 Drop feed lever
#4 Free arm
#5 Buttonhole lever
#6 Presser foot lifter
#7
Hole for additional spool pin
q
w
e
r
t
y
u
i
o
!0
!1
!2
!3
!4
!5
!6
!7
!8
!9
@0
@1
@2
@3
@4
@5
@6
@7
@8
@9
#0
#1
#2
#3
#4
#5
#6
#7
NOTE:
The specifications are subject to change without prior notice.
