24
z
x
c
v
q
w
e
r
• Inserting the bobbin
q End of thread
w Notch
e Notch
r Threading diagram
z Place a bobbin in the bobbin holder with the thread
running off counterclockwise.
x Guide the thread into the first notch w on the front
side of the bobbin holder. Draw the thread to the left,
sliding it between the tension spring blades.
c Continue to draw the thread lightly until the thread
slips into the second notch e. Pull out about 6˝
(15 cm) of thread.
v Attach the hook cover plate. Check the threading by
referring to the diagram r shown on the hook cover
plate.
