Janome HD3000 - Additional Clearance; Pressure Dial; Dropping the Feed Dogs

5
A
B
Additional Clearance
The presser foot can be raised higher for additional
clearance.
Pressure Dial
The pressure dial should be set at “3” for regular sew-
ing. Reduce the pressure to “2” for appliques.
Set the pressure to “1” when sewing chiffon, lace,
organdy and other ne fabrics. Velours and knits with
a lot of stretch may also require a “1” setting.
Dropping the Feed Dogs
Drop feed lever is located underneath of free arm bed.
A: To raise the feed dogs, push the lever to the
direction of arrow as illustrated.
B: For dropping the feed dogs, push the lever to the
direction of arrow as illustrated.
* Feed dogs must always be up for normal sewing.
