Janome JP720 - Stepping Motor (Feed) Replacement

29
Stepping motor ( Feed )
Replacing the Electronic Components
To remove:
1. Remove the front cover and the rear cover.
2. Remove 2 screws .
3. Remove E-ring .
4. Remove stepping motor (Feed).
To attach:
1. Follow the above procedures in reverse.
NOTE:
* Check the stretch stitch balance after replacing the stepping motor.
q
q
w
w
