33
WARNING:
Turn the power switch off and unplug the
machine before cleaning.
Cleaning the Hook Race and Feed Dogs
z Remove the presser foot and needle. Remove
screw on the needle plate with the
screwdriver.
Remove the needle plate and take out the
bobbin.
q Screw
x Lift up the bobbin holder and remove it.
w Bobbin holder
NOTE:
• Do not dismantle the machine other than as
explained in this section.
• Do not store the machine in a high-humidity
area, near a heat radiator, or in direct
sunlight.
• Clean the outside of the machine with a
soft cloth and mild soap.
c Brush out dust and lint.
e Lint brush
v Clean the feed dogs and hook area with the
lint brush.
r Feed dogs
b Wipe the hook race with a soft, dry cloth.
t Hook race
NOTE:
You may also use a vacuum cleaner.
SECTION 6. CARE AND MAINTENANCE
c
q
w
e
r
t
z
x
v
b
