31
MS5027PR
MECHANICAL ADJUSTMENT
ZERO FEEDING
ADJUSTMENT PROCEDURE:
1. REMOVE THE BELT COVER (SEE PAGE 9).
2. SET THE STITCH SELECTOR AT " ", AND THE STITCH LENGTH CONTROL AT "0".
3. PLACE A PIECE OF PAPER ON THE NEEDLE PLATE.
4. IF THE PAPER MOVES FORWARD, TURN THE ADJUSTING SCREW (C) IN DIRECTION (A).
IF THE PAPER MOVES BACKWARD, TURN THE ADJUSTING SCREW (C) IN DIRECTION (B).
BACKWARD
FORWARD
(A)
(B)
(C)
