Janus 2000 - Brackets Mount to Steel Jambs Via Mounting Plates

10
(3)
3
8-16 X 1-
1
4
HEX-HEAD BOLT
(3)
3
8" FLAT WASHER
GUIDE MOUNTINGS (CONTINUED)
NOTE: DOOR CAN FALL IF BOTH BRACKETS ARE NOT SECURELY FASTENED TO THE
JAMBS. ALL FASTENERS ATTACHING BRACKETS TO JAMBS MUST FIT SECURELY
INTO A STRUCTURAL MEMBER OR SURFACE. IF DOOR FALLS, SERIOUS INJURY OR
DEATH AND/OR DAMAGE TO DOOR CAN RESULT.
FIGURE 11:
BRACKETS MOUNT TO STEEL
JAMBS VIA MOUNTING PLATES
(3)
3
8" LOCK NUT
(3)
3
8"FLAT WASHER
