Jayco PINNACLE - Emergency Towing; Wheel Lugs

49
VEHICLE OPERATION
NOTE:&XUYHVDQGRUKLOOVPD\DIIHFWWKHVDIHSODFHPHQWRIZDUQLQJ
indicators.
)RUSHUVRQDOVDIHW\DOZD\VVWDQGRIIWKHURDGDQGRXWRIWKHZD\RIWUDI¿F
9#40+0)
EMERGENCY TOWING
If your recreational vehicle needs to be towed, please contact an emergency road service
SURYLGHURUDTXDOL¿HGVHUYLFHIDFLOLW\IRUDVVLVWDQFH
Never allow anyone to go under the recreation vehicle while it is being lifted
and/or being towed.
9#40+0)
NOTE: The proper method of tightening wheel lug nuts is with a
properly calibrated torque wrench and socket, not with an impact
wrench or by hand. Do not use a 4-way lug wrench or any
other type of wrench that does not measure the actual
pressure applied to the lug nut.
WHEEL LUGS
$IWHU\RXU ¿UVWWULS FKHFN WKHZKHHO OXJWRUTXH SHULRGLFDOO\ IRUVDIHW\ &KHFN WKHZKHHO
lugs after winter storage, after a wheel removal, before starting a trip or following extensive
braking. Use the correct star pattern sequence to attach the recreation vehicle wheels (see
Wheel Lug Torque Chart.)
1. Start all nuts by hand to prevent cross threading.
2. Tighten the nuts in the sequence shown.
3. Tighten the lug nuts equally in stages as indicated for your recreational vehicle wheels
(see Wheel Lug Torque Chart).
&KHFN DQG UHWRUTXHDIWHU WKH ¿UVW   DQG  PLOHV   DQG  NLORPHWHUV
Thereafter, check and maintain the torque according to the listed torque values (see
Wheel Lug Torque Chart.)
Because of the importance of having proper torque on the wheel lug nuts, you should always
KDYHWKHZKHHOVPRXQWHGDQGSURSHUO\WRUTXHGE\DTXDOL¿HGWHFKQLFLDQXVLQJWKHSURSHU
tools.
