VEHICLE OPERATION
When replacing a tire make sure to replace it with a tire of the same size and
VSHFL¿FDWLRQVUHIHUWRWKH)HGHUDO&HUWL¿FDWLRQODEHO
9#40+0)
SPARE TIRE CARRIER (IF SO EQUIPPED)
If your recreation vehicle is equipped with a spare tire, it will either be mounted under the
unit (hoist) or on the rear bumper.
Hoist mount
Depending on your model, the spare tire may have (side or bottom) brackets or it will be
PRXQWHGDJDLQVWWKHXQGHUVLGHRIWKHUHFUHDWLRQYHKLFOHÀXVKPRXQWWRJLYHLWVWDELOLW\LQ
travel.
Raising and lowering the hoist
In most cases the crank handle to raise and lower the tire will be located
in a basement compartment of the recreation vehicle. Typically, it is
fastened to the sidewall of the compartment. Insert the crank handle
into the crank access port located either in the center of the rear bumper,
or in the sidewall of the RV. Turn the crank handle to lower the tire, or
to lift into the travel position. Two “crisp breaks” must be heard and felt
to insure the proper seating of the tire for travel.
DO NOT exceed the maximum load capacities of 100 lbs. for the hoist. DO
NOT use air driven guns or impact wrenches to lift the spare tire to the travel
position.
9#40+0)
If you have questions regarding your tires, contact the tire manufacturer or Jayco
Customer Service.
Hoist mount spare tire position
Crank access port
+RLVWPRXQWÀXVKPRXQWWUD[HOSRVLWLRQ
NOTE:,I\RXUVSDUHWLUHLVDÀXVKPRXQWDSSOLFDWLRQLWPXVWPDNH
FRQWDFWZLWKWKHXQGHUVLGHRIWKHUHFUHDWLRQYHKLFOHWRLQVXUHPD[L-
mum road clearance and stability in travel.
