57
VEHICLE OPERATION
OPERATING POWER AWNINGS (IF SO EQUIPPED)
Your recreation vehicle may be equipped with multiple (power) awnings which will each
have its own control switch. The control switch(s) for each awning is typically located on
the command center switch panel located inside the entrance door. Pressing and holding the
switch will extend or retract the awning.
Carefree® LONGITUDE Awnings (If So Equipped)
These awnings offer various features that make them easy and convenient to use. These
features include:
Scissor style arms that do not require vertical ground supports.
Adjustable arms that provide easy to use 6 position pitch adjustment
Roller tube and arms that are made from light weight no-rust aluminum
100% billow-proof worm gear driver motor eliminating the need for travel locks.
Single switch operation, 12V motorized awning.
Refer to the manufacturer’s user guide for detailed operating and safety information.
Adjusting the Awning Pitch
The longitude arms have 6 pitch adjustment settings from minimum pitch to maximum
pitch. The awning can be extended and retracted in any of these positions without having to
reset the pitch between uses.
Do not set the individual arm pitch at more than three (3) positions different
between the left and right arms. Damage to the arms and the canopy can occur
if the awning is retracted when the arms are set at more than three (3) positions
difference.
9#40+0)
Use care when adjusting the pitch as the awning may move abruptly.
%#76+10
Awnings must be closed (and locked if applicable) while the RV is in transit.
9#40+0)
The effects of wind and rain on an awning are unpredictable and can cause
severe damage to the awning and/or the recreation vehicle. If wind or extended
periods of rain are expected, retract the awning.
%#76+10
It is recommended that if leaving the recreation vehicle unattended for a length
of time, retract the awning to avoid unexpected climate conditions.
%#76+10
