61
SLIDEOUT SYSTEMS
Make sure the interior slideout room path and the slideout room itself is clear
of people and objects before operating. Keep away from the slide rails and
gear assembly when the room is in motion. They may pinch or catch on loose
clothing causing personal injury. Failure to follow these instructions could
result in serious injury or death.
9#40+0)
Make sure the vehicle is level before operating the slideout room. Water leaks
and other problems could result if the slideout is operated without leveling the
vehicle.
%#76+10
Make sure the slideout is in the closed position prior to hooking the unit to
the tow vehicle.
%#76+10
Do not place excessive weight in the slideout room. It can cause the slideout
room to malfunction and cause damage to the slideout.
%#76+10
ELECTRIC SLIDE ROOM SYSTEM (IF SO EQUIPPED)
7KHVOLGHRXWURRPV\VWHPLVGHVLJQHGIRUDGGLWLRQDOÀRRUVSDFHDQGFRPIRUW7KHPHFKDQLFDO
components are gear driven. Electric powered slideout room systems have a manual override
to allow you to extend or retract the slideout room(s) in case of a power loss. Make sure you
KDYHVXI¿FLHQWSRZHUDYDLODEOHEHIRUHRSHUDWLQJ\RXUVOLGHRXWV\VWHP
The auxiliary battery (customer supplied) must be fully charged and connected. If
possible, the RV should be hooked up to 120-volt AC power so the converter operates.
The RV must be level and the stabilizer jacks in the extended position.
Locate the slideout control switch. To move the room out, press the OUT section of the
switch and hold it until the motor stops (travel time is approx. 25 seconds). Operating
the switch after the room is fully extended will damage the switch and motor.
Additional support jacks are not needed under the slideout. Damage can occur
to your slideout room from improper use of aftermarket support jacks.
%#76+10
