Jayco PINNACLE User Manual

67
SLIDEOUT SYSTEMS
Refer to the Schwintek Slide Room Operation Guide for further information. Call Lippert at
(866) 524 – 7821 or visit the Lippert website at www.lci1.com for additional troubleshooting
information.
Flush Floor Slideout
For optimum performance, the slide-out system requires full battery current and voltage.
Although the system is designed to be almost maintenance free, actuate the room once or
twice a month to keep the seals and internal moving parts lubricated. Check for any visible
signs of external damage after and before movement of the travel trailer.
7URXEOHVKRRWLQJWKHÀXVKÀRRUVOLGHRXW
If the slideout does not move when the slideout switch is depressed, follow these steps.
 Check the auxiliary battery (customer supplied) for a full charge and good wire
connections.
 Check the 12-volt fuse or circuit breaker.
 Check for loose connections at the slideout motor.
 If the slideout still will not operate, follow these steps.
 ,I WKH VOLGHRXW LV H[WHQGHG UHIHU WR WKH IROORZLQJ VHFWLRQ RQ RYHUULGLQJ WKH VSHFL¿F
slideout system installed on your RV.
 If the slideout is retracted, leave it in that position.
 Contact your dealer or customer service for repair assistance.
 If the slideout extends crooked or only one side moves, follow these steps.
 )ROORZVWHSVRQRYHUULGLQJWKHVSHFL¿FVOLGHRXWV\VWHPLQVWDOOHGRQ\RXU59
 You may need to push the side that is not sliding to get it to retract all the way.
 Contact your dealer or customer service for repair assistance.
0DQXDO2SHUDWLRQIRUWKHÀXVKÀRRUVOLGHRXW
The electric slide comes with a manual over ride system. Locate the crank extension under
the inside of the frame (refer to Fig. 1 and 2).
7KLVLVZKHUHWKHFUDQNKDQGOHVWDQGDUG¿IWKZKHHOODQGLQJJHDUFUDQNKDQGOHRU´VRFNHW
DQG UDWFKHW ¿WV RQ WR DOORZ WKH PDQXDO H[WHQVLRQUHWUDFWLRQ RI WKH URRP )LJ  DQG 
Simply take the wrench, ratchet or drill with a nut driver and rotate it clockwise to retract
and counterclockwise to extend slide-out.
NOTE: For long-term storage it is recommend the room be closed
UHWUDFWHG
Always disconnect battery from system prior to manually operating system.
Failure to disconnect battery can cause electricity to backfeed through the
motor and cause serious damage to the system as well as void the warranty
%#76+10
