16
www.jbhmedical.com
FOLDING AND UNFOLDING
Photo 19. Steps for wheelchair folding
Photo 20. Steps for wheelchair unfolding
Making sure all the attaching parts are fastened properly after any adjustment , repair or
maintenance, for avoiding any damage or injury.
The wheelchair with certain weight that requires correct way of lifting up to avoid injury.
While it is necessary to lift up for moving the wheelchair, it is strong suggested user get off
wheelchair first.
If user have to stay in wheelchair for lifting up and moving at the same time, make sure
safety is fully secured. Do not hold attaching part for lifting and moving wheelchair.
◎ Steps for Wheelchair Folding
Push down the red button with one hand and push the top of bakrest toward front
with another hand.
Hold top of backrest frame with one hand, the other hand lift up the front seat base
under seat cushion, then both hand push to the center of chair for folding.
Push top of back rest and front end of seat together.
Fold foot pedal.
1.
2.
3.
4.
Unfold foot pedal first.
Hold the top of backrest with one hand, the other hand hold front end of seat.
Both hand push away till a “Click” sound heard for completely unfold the wheelchair.
◎ Steps for Wheelchair Unfolding
1.
2.
3.
To Next Page
