17
www.jbhmedical.com
Photo 21. Release the rear wheels
REMOVABLE MOTOR/WHEEL SUBASSEMBLY
Your D26 Power Wheelchair may have come with Quick Release Wheels to reduce the-
overall weight of your D26 .
Reverse these steps to assemble the wheels again before using your D26 model.
To release the rear wheels,first unplug the quick connect cables at the back of the unit.
Remove the locking pin and slide the wheels horizontally off the locking plate
1.
2.
Photo 22. Remove the locking pin
Photo 23. Slide out wheel assembly
