Toslink / Optical Digital-in
1. ConnectopticalcablebetweensourcecomponentandtheToslink/OpticalInput
on the back of the Primary Speaker.
2. RotatetheSourcecontroltotheOpticalAudioinput,theOpticalAudioLEDwill
illuminate solid White.
3. Start your content.
Balanced XLR / ¼" Connection
1. ConnectBalancedLeft&RightXLRor¼"cablesbetweensourcecomponent
andtheBalancedLeft&RightInputsonthebackofthePrimarySpeaker.
2. RotatetheSourcecontroltotheBalancedAudioinput,theBalancedAudioLED
will illuminate solid White.
3. Start your content.
NOTE:
SelectappropriateSensitivitylevelinsupportofcontent/sourceinput–
(-10dB/Highsensitivitymodeor+4dB/Lowsensitivitymode).
Analog Auxiliary (3.5mm Aux-in) Connection
1. ConnectanalogStereocablebetweensourcecomponentandtheanalog3.5mm
StereoAuxiliaryInputonthebackofthePrimarySpeaker.
2. RotatetheSourcecontroltotheAuxiliaryinput,theAuxiliaryAudioLEDwill
illuminate solid White.
3. Start your content.
7. System Control
Volume Up / Down / Mute
The volume control on the Primary speaker will raise or lower the volume level for both speakers simultaneously.
• Fromthedefaultvolumelevel,turningtheVolumecontrolClockwisewillincreasethe
volume in 1dB increments.
• LEDswillashWhitewhenmaximumvolumehasbeenreached.
• TurningtheVolumecontrolCounter-Clockwisewilldecreasethevolumein1dBincrements.
• PresstheVolumeControltoinitiateMutefunction.SelectedSourceLEDwillilluminate
andashRedwhileMutefunctioninitiated.(Opticalinputisbeingexempliedinthe
graphictotheright)
• PresstheVolumeControlagainwillun-Mute,restoringvolumetolastsetting.
NET
VOLUME/MUTE SOURCE/PAIRING
Source
Primary Speaker
NET LED remains On as long as the
network connection is stable
NET
VOLUME/MUTE SOURCE/PAIRING
Source
Primary Speaker
NET LED remains ON as long as the
network connection is stable
NET
VOLUME/MUTE SOURCE/PAIRING
Source
Primary Speaker
NET LED remains ON as long as the
network connection is stable
NET
VOLUME SOURCE/PAIRING
POWER
NET
SOURCE/PAIRING
/MUTEVOLUME
Flashing
Primary Speaker
