L / R SUM
The main MIX L & R signals are combined (summed) and sent to the L/R SUM output jack. Output
level is set by this rotary control.
CONTROL ROOM & PHONES LEVEL
These controls set the output level to the control room LEFT & RIGHT and HEADPHONE outputs.
If HEADPHONES are plugged into the PHONES jack, the Control Room outputs are cut off and the
knob then sets the headphone listening level. When the PHONES are unplugged the Control Room
output is restored. When any LISTEN switch is pressed, the LISTEN signal is sent to the Control
Room Outputs and Headphones without interrupting the other outputs from the mixer. The LISTEN
LED illuminates to show that LISTEN is the source for the monitors and meters. The original
monitor source is restored when the LISTEN switches are released.
MIX T
APE/CD
Pressing the MIX TAPE/CD switch routes the TAPE/CD IN source to headphones, meters and
control room monitors. The MIX output will not be heard in headphones, meters and control room
monitors when this switch is in the TAPE/CD position (depressed).
T
APE/CD LEVEL
The rotary control sets the level of the TAPE/CD input.
T
APE/CD IN TO MIX
Press this switch to add the TAPE/CD IN signal to the stereo Mix, at a level set by the TAPE/CD
LEVEL control. The signal is added pre-insert, pre-fader, and is an ideal way of feeding pre-show
music to the mix in live applications, or could be used as an alternative effects return or line level
input if required.
MON MASTER
The MON (Monitor) master control adjusts the overall level of the MON output used to feed stage
monitors.
EFX2 / MON2 MASTER
This control adjusts the overall level of the EFX2 / MON2 output which may be used to feed stage
monitors or effects processors.
EFX MASTER
The EFX (Effects) master control adjusts the overall level of the EFX output used to feed an effects
processor.
LISTEN (MON, EFX2 / MON2, EFX)
Routes the associated output signal to the CONTROL ROOM or PHONES, replacing any existing
signal. The METERS also switch from the selected source to display the LISTEN signal and the
LISTEN LED lights to warn that a LISTEN switch is pressed. The level of the signal heard on the
headphones or the control room monitors depends on the setting of the associated master level
controls.
EFX2 / MON2
Determines if the EFX2 / MON2 send is configured for use with effects processors (EFX2) or to
drive stage monitors (MON2).
• Select the MON2 position (depressed) to make all the EFX2 / MON2 sends PRE-FADE, POST-EQ.
This means that they will all be unaffected by the position of the channel faders, making them
ideal for foldback or monitoring.
• Select the EFX2 position (disengaged) to make all the EFX2 / MON2 sends POST-FADE, POST-
EQ. This means they will fade up and down with the channel faders. This is more suitable for
effects sends.
MIX L & R – Master Faders
The MIX L & R faders set the final level of the LEFT OUT and RIGHT OUT.
