JBL EVOi.sys - EVO Wireless Receiver System Controller

EVO WIRELESS RECEIVER
SYSTEM CONTROLLER
The EVO Wireless Receiver System Controller consists of a
pair of stationary true-microcontrolled diversity receivers for
use with EVO microphone transmitters. Each EVO Wireless
Receiver operates in a subband of up to 4 MHz wide across
the 710 MHz to 861 MHz UHF range. Each unit can be
switched to a maximum of 15 different carrier frequencies,
depending on local frequency allocations.
24
MICROPHONE OPERATION
BALANCED UNBALANCED
BALANCED
LINE MIC
POWER
AC/DC 12-16 V
20 mA
Set: XXXX
SNR: XXXXX
For IM-free frequencies
refer to manual
1
2 3
6
8
9
4 5 7
13 15
16
14
12
1
Front Panel
Rear Panel
Securing the
Power Cord
10 11
