TECHNICAL DATA
EVOi.sys Specifications
Noise
Measured RMS 20 Hz to 20 kHz Bandwidth
Mic. E.I.N. @ max gain 150W source impedance -129 dBu
Aux, Mix & Masters @ max.,
16 inputs routed with faders, pots down < -80 dBu
Crosstalk (@l kHz, typical) Channel Mute < 96 dB
Fader cut-off (rel. 0 mark) < 90 dB
Routing Isolation < 90 dB
Aux Send pots offness < 84 dB
Frequency Response
Mic/Line Input to any output 20 Hz - 30 kHz < .05 dB
THD + N
Mic sens. -30 dBu, + 14 dBu at all outputs @ l kHz < 0.009%
Input & Output Impedance
Mic Input 1.8 kW
Line Input 10 kW
Stereo Return Input (Balanced jack) 10 kW
2TK Return (Unbalanced RCA Phono) 12 kW
Mix, Aux, Direct Outputs, and Insert Sends 75 W
Input and Output Levels
Mic Input max. level +22 dBu
Line Input max. level < +30 dBu
Stereo Return Input max. level < +30 dBu
Headphones (@ 200 Ohms) 150 mW
