30
TECHNICAL DATA
710 to 860 MHz
FM
50-20.000 Hz
+/- 10 ppm
30kHz
< 0.5%
Yes
typ 50 dB(A)
10mW
typ 130 mA
2 x AA
>10h
350mV/ 1 kHz
220v.Ohm
240 x 36 mm
(9.45 x 14.17 in.)
245 g (9.8 oz.)
710 to 860 MHz
FM
50-20.000 Hz
+/- 10 ppm
30kHz
< 0.5%
Yes
typ 50 dB(A)
Yes
10mW
typ 130 mA
2 x AA
>8h
350mV/ 1 kHz
220v.Ohm
Pin 3-6V/6k8
92 x 65 x 20 mm
(3.62 x 2.56 x 0.79 in.)
76 g (3.04 oz.)
710 to 860 MHz
FM
50-20.000 Hz
< 0.4%
Yes
>100 dB(A)
Yes
typ 145 mA
typ. -95 dBm
-95 to -80 dBm
Balanced XLR: MIC/Line level switchable; typ.
30 dB Unbalanced 1/4” Jack:
0 dBm XLR; 6 dBm
210 x 170 x 42 mm
(8.27 x 6.70 x 1.65 in.)
470 g (18.8oz.)
Carrier Frequency
Modulation FM
Audio Bandwidth
Frequency Stability
(-10 degrees C to +45 C degrees ETS +30
degrees C to +60 degrees C FCC)
Rated devation
T.H.D. at 1 kHz
Compander Characteristics
S/N Ratio
Limiter
RF-Output
Current Consumption
Power Requirement
Battery Life
Input Sensitivity
Audio Input-related Deviation
Input Impendance
Phantom Power
Squelch Threshold
Audio Output
Size (W x D x H)
Net Weight g (oz)
HANDHELD BODYPACK RECEIVER
UHF Transmitters
EVO Microphones-Wireless
