TECHNICAL DATA
Dynamic Pressure Gradient Microphone
Polar pattern: Supercardioid
Frequency range: 60 to 20,000 Hz; at 1 cm: 20 to 20,000 Hz
Sensitivity at 1000 Hz: 2.5 mV/Pa (-52 dBV) re 1 V/Pa
Impedance at 1000 Hz: <600 ohms
Recommended load impedance: >2000 ohms
Max. SPL for 1 % (3 %) THD: 147 dB SPL (156 dB SPL)
Equivalent noise level: 22 dB(A) (DIN 45412)
Environment: Temperature: -10º C to +60º C
Rel. humidity at +20º C: 95 %
Connector: 3-pin XLR
Connector pinout: Pin 1 ground
Pin 2 hot
Pin 3 return
Case material: Die-cast zinc alloy
