JBL FLIP 3 Service Manual

Trouble shooting Chart
Cannot charging
Cannot charging
Go
Yes
Replace U3 or change another
battery
No
Check U3 pin18 in main Board, whether
the volta
g
e ≥0.6V
No
Replace R18 R19
Yes
No
Replace L6
Yes
Replace 24pin FFC Check 24pin FFC whether has it
breakage and connect well?
Check L6, whether has it breakage
and connect well?
5-1

JBL FLIP 3 Specifications

General

Speaker type	-
Driver diameter	40 mm
Number of drivers	2
Number of speakers	1
Audio output channels	- channels
Impedance	- Ω
Frequency range	85 - 20000 Hz
RMS rated power	16 W
Signal-to-Noise Ratio (SNR)	80 dB
Bluetooth version	4.1
USB charging port	Yes
Bluetooth profiles	A2DP, AVRCP, HFP, HSP
USB connector type	Micro-USB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wireless
Battery voltage	3.7 V
Battery capacity	3000 mAh
Power source type	Battery
Battery life (max)	10 h
Battery recharge time	3.5 h
Product color	Turquoise
Protection features	Splash proof
Recommended usage	Universal
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	64 mm
Width	169 mm
Weight	450 g
