JBL FLIP 3 Service Manual

Trouble shooting Chart
keys do not work
Keys do not work
Go
No
Check 3.3v of U1 PIN5 in main board .
Yes
Replace the U3 in the main board.
Yes
No
Check Q1 Q11. whether has it
breakage or plug in well?
Check XP4 10PIN FFC in main board
whether has it breakage or plug in well?
Fix or replace the 10PIN FFC
Yes
Replace the Q1 Q11 in the main
board.
No
Replace the Key board.
5-2

JBL FLIP 3 Specifications

General

Speaker type	-
Driver diameter	40 mm
Number of drivers	2
Number of speakers	1
Audio output channels	- channels
Impedance	- Ω
Frequency range	85 - 20000 Hz
RMS rated power	16 W
Signal-to-Noise Ratio (SNR)	80 dB
Bluetooth version	4.1
USB charging port	Yes
Bluetooth profiles	A2DP, AVRCP, HFP, HSP
USB connector type	Micro-USB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wireless
Battery voltage	3.7 V
Battery capacity	3000 mAh
Power source type	Battery
Battery life (max)	10 h
Battery recharge time	3.5 h
Product color	Turquoise
Protection features	Splash proof
Recommended usage	Universal
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	64 mm
Width	169 mm
Weight	450 g
