JBL FLIP 3 Service Manual

Mechanical Exploded View:
Part Number List for the Exploded View
skrameRrebmuN traPnoitpircseD.oN
2 1.5” full range Speaker 42-015008-04001
10000-0950EN-45
rotaidaR evissaP5
AH0-1D3PLF-20yssa revoc yrettab6
7 Li-ion polymer Battery 3.7V 3000mAh 49-373000-BAT5-M
0YK-U207BW-80draoB YEK9
0EF-U207BW-80draoB DEL01
2BHU0-1H3PLF-55 n StandiaM31
2BHU0-1C3PLF-55revoC BSU41
16
56 FLP3H4 0HAB2
2BAH0-4H3PLF-6561
0NI-U207BW-80draoB BSU71
HU0-1I3PLF-55ydoB niaM91
0AM-U207BW-80draoB niaM12
22 MIC Φ4.0/2pin JST 1.5mm IP5X water resistant 02-MIC025-XX0
USB Bracket
9
For spare parts numbers for outer grille #1, please
refer to Spare Parts List below, page 29.

JBL FLIP 3 Specifications

General

Speaker type	-
Driver diameter	40 mm
Number of drivers	2
Number of speakers	1
Audio output channels	- channels
Impedance	- Ω
Frequency range	85 - 20000 Hz
RMS rated power	16 W
Signal-to-Noise Ratio (SNR)	80 dB
Bluetooth version	4.1
USB charging port	Yes
Bluetooth profiles	A2DP, AVRCP, HFP, HSP
USB connector type	Micro-USB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wireless
Battery voltage	3.7 V
Battery capacity	3000 mAh
Power source type	Battery
Battery life (max)	10 h
Battery recharge time	3.5 h
Product color	Turquoise
Protection features	Splash proof
Recommended usage	Universal
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	64 mm
Width	169 mm
Weight	450 g
