JBL FLIP 3 Service Manual

1.3 Bluetooth Section
1.3.1 General
Description Specification
Bluetooth Standard Version 4.1
Frequency Band 2.402 – 2.480 GHz
Host Interface UART
Profile Supported HFP (Audio Gateway and Handsfree)
A2DP (Advanced Audio Distribution Profile)
AVRCP (Audio/Video Remote Control Profile)
Refer SRD
Audio Codec SBC (Subband Codec)
Data Rate 2.1Mbps (over the air)
300Kbps (over UART)
Antenna External
Certification CE, FCC, BQE
1.3.2 Transmitter Performance @BDR Mode
Description Specification
Maximum Transmit Power @ antenna
connector
0 ~ 4dBm(class II)
Power Control Maximum Power Step <=8dB
Minimum Power Step >=2dB
Initial Carrier Frequency Shift +/- 75KHz
Carrier Drift
- Drift Rate
- Drift (Single Slot Packet)
- Drift (Three Slot Packet)
- Drift (Five Slot Packet)
+/- 20KHz/50us
+/- 25KHz
+/- 40KHz
+/- 40KHz
Modulation Characteristic
- F1avg
- F2 Max Pass rate
- F1/F2 Ratio
140KHz – 175KHz
>=115KHz
>= 0.8
1.3.3 Receiver Performance
Description Specification
Single Slot Sensitivity @ <=0.1%BER <= -85dBm
Multiple Slot Sensitivity @ <=0.1%BER <= -85dBm
Maximum Input Level @ <= 0.1% BER >= -20dBm
2-3

JBL FLIP 3 Specifications

General

Speaker type	-
Driver diameter	40 mm
Number of drivers	2
Number of speakers	1
Audio output channels	- channels
Impedance	- Ω
Frequency range	85 - 20000 Hz
RMS rated power	16 W
Signal-to-Noise Ratio (SNR)	80 dB
Bluetooth version	4.1
USB charging port	Yes
Bluetooth profiles	A2DP, AVRCP, HFP, HSP
USB connector type	Micro-USB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wireless
Battery voltage	3.7 V
Battery capacity	3000 mAh
Power source type	Battery
Battery life (max)	10 h
Battery recharge time	3.5 h
Product color	Turquoise
Protection features	Splash proof
Recommended usage	Universal
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	64 mm
Width	169 mm
Weight	450 g
