JBL FLIP 3 Service Manual

Technical Specifications
1 Audio Section
1.1.1 Speaker Output
Description Specification
Rated Output Power 2 x 8W +-10% (Measure before power limiter at 1% THD).
Please refer to Acoustic Design Specification.
Input Sensitivity Aux : 370mV +/- 10%
Wireless input:-9dBfs +/-1dB
Input Overload Aux : 1V rms
BT: 0dBFS
Auto Turn On Input Sensitivity @1KHz, Typical : 2mV Limit : 4mV
@100Hz Typical : 10mV Limit :15mV
Frequency Response (Output Power) Aux_in : 40Hz to 20KHz +/- 1dB (EQ setting is disable)
BT: 20Hz to 19KHz +/- 1dB (EQ setting is disable)
Frequency Response (Output Power) with
EQ setting
TBC
THD+N at 1W <0.5%@100hz/7khz, else<0.3%
THD+N at Rated Output Power <1%
Signal-to-Noise ratio at Rated Output Power 80dB (A-Weighted)
Channel Separation 45dB @100Hz
50dB @1KHz
45dB @10KHz
Channel Crosstalk 80dB @100Hz
75dB @1KHz
70dB @10KHz
Inter Channel Gain Difference <0.5dB
Residual Noise 80nW
2-1

JBL FLIP 3 Specifications

General

Speaker type	-
Driver diameter	40 mm
Number of drivers	2
Number of speakers	1
Audio output channels	- channels
Impedance	- Ω
Frequency range	85 - 20000 Hz
RMS rated power	16 W
Signal-to-Noise Ratio (SNR)	80 dB
Bluetooth version	4.1
USB charging port	Yes
Bluetooth profiles	A2DP, AVRCP, HFP, HSP
USB connector type	Micro-USB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wireless
Battery voltage	3.7 V
Battery capacity	3000 mAh
Power source type	Battery
Battery life (max)	10 h
Battery recharge time	3.5 h
Product color	Turquoise
Protection features	Splash proof
Recommended usage	Universal
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	64 mm
Width	169 mm
Weight	450 g
