JBL JSR-400 - Disassembly Procedures

10
Dolby Pro-Logic
Ò
A/V Receiver JSR-400
DISASSEMBLY PROCEDURES
J
B
L
JBL
J
B
L
JBL
STEP 1.
REMOVING THE TOP COVER
1. REMOVING THE SCREWS 1~9
STEP 2.
REMOVING THE BOTTOM COVER
1. REMOVING THE SCREWS 1~8
STEP 3.
REMOVING THE FRONT PANEL
1. REMOVING KNOB VOLUME MAIN FROM FRONT PANEL
2. REMOVING THE SCREWS 1~12
1
1
4
4
3
3
2
2
9
6
6
6
8
8
5
5
5
8
9
4
3
2
1
12
11
10
7
7
7
KNOB VOLUME MAIN
