2) VCO VS. FM BAND FREQUENCY CURVE.
3) VCO VS. AM BAND FREQUENCY CURVE.
87.5 89.5 91.5 93.5 95.5 97.5 99.5 101.5103.5 105.5 107.5
V Voltage (V)
CO
8
7
6
5
4
3
2
1
0
FM Band Frequency (MHz)
520 600 700 800 900 1000 1100 1200 1300 1400 1500 1600
V Voltage (V)
CO
9
8
7
6
5
4
3
2
1
0
AM Band Frequency (kHz)
