SRX818SP SPECIFICATIONS
System Specification
System Type: Self powered 18”, subwoofer system
Maximum SPL Output: 135dB
Frequency Range (-10dB): 29Hz - 150Hz
Frequency Response (-3dB): 35Hz - 120Hz
Amplification
System Power Rating: 1000W Peak , 750W Continuous
Input Impedance: 40k balanced, 20k unbalanced
Line Input Gain: 21 dB
Maximum Input Level:
s
Line: 20dBu
Connectors: Neutrik 1/4 - XLR input; Neutrik XLR Output
LED Indicators: Power LED (Green), Network Link (Green), Network Data (Yellow)
Cooling: On-Demand variable speed fan
AC Power Input: 100 - 240V~ 50/60Hz
AC Power Consumption (120V~): 2.2A (1/8th Power), 5.6A (1/3rd Power)
Speaker Specification
LF Driver: 2279F
Crossover Frequency: 80Hz
Enclosure
Material: 18mm plywood
Suspension/Mounting: M20 Threaded Pole Mount
Handles: 4
Finish: Obsidian Duraflex™ finish
Grille: Powder coated, Obsidian, 14-gauge perforated steel with acoustically transparent black cloth backing
Dimensions (L x W x H): 26.89” x 26.92” x 22.62” (683mm x 684mm x 575mm)
Weight: 87.0 lbs (39.5kg)
Shipping Weight: 103 lbs (46.8kg)
*For exact specifications including precise placement of suspension points and frequency response curves for JBL presets, find spec sheets at
http://www.jblpro.com/www/products/portable-market/srx800-series
Bottom View Front View Left View Rear View
683 mm
26.89 in
575 mm
22.62 in
684 mm
26.92 in
