JBL SRX828SP User Manual

21
SRX828SP SPECIFICATIONS
System Specification
System Type: Self powered dual 18”, subwoofer system
Maximum SPL Output: 141dB
Frequency Range (-10dB): 29Hz - 150Hz
Frequency Response (-3dB): 35Hz - 120Hz
Amplification
System Power Rating: 2000W Peak (1000W x 2), 1500W continuous (750W x 2)
Input Impedance: 40k balanced, 20k unbalanced
Line Input Gain: 21 dB
Maximum Input Level:
s
Line: 20dBu
Connectors: Neutrik 1/4 - XLR input; Neutrik XLR Output
LED Indicators: Power LED (Green), Network Link (Green), Network Data (Yellow)
Cooling: On-Demand variable speed fan
AC Power Input: 100 - 240V~ 50/60Hz
AC Power Consumption (120V~): 2.2A (1/8th Power), 5.6A (1/3rd Power)
Speaker Specification
LF Driver: (2x) 2279F
Crossover Frequency: 80Hz
Enclosure
Material: 18mm plywood
Handles: 8
Finish: Obsidian Duraflex™ finish
Grille: Powder coated, Obsidian, 14-gauge perforated steel with acoustically transparent black cloth backing
Dimensions (L x W x H): 26.79” x 47.42” x 22.57” (681mm x 1205mm x 574mm)
Weight: 145.0 lbs (65.9kg)
Shipping Weight: 165.0 (75.0kg)
*For exact specifications including precise placement of suspension points and frequency response curves for JBL presets, find spec sheets at
http://www.jblpro.com/www/products/portable-market/srx800-series
Bottom View Front View Left View Rear View
680 mm
26.79 in
573 mm
22.57 in
1204 mm
47.42 in

JBL SRX828SP Specifications

General

Frequency Response (-10dB)	29 Hz - 150 Hz
Frequency Response (-3dB)	35 Hz - 120 Hz
Max SPL Output	141 dB
Power Rating	2000W Peak
Amplifier Design	Class D
AC Power	100V - 240V ~ 50/60 Hz
System Type	Self-powered dual 18" subwoofer
Input Connectors	2 x XLR-1/4" combo jacks
Input Impedance	20k ohms balanced, 10k ohms unbalanced
Signal Indicators	Limit, Signal, Power
Cooling	Variable speed fan
Enclosure	18 mm plywood
Grille	Powder coated, perforated steel
LF Driver	2 x 18"
Finish	Black DuraFlex finish
