Travel Equipment
Type Fixed Displacement Piston Motor (automatic 2-speed change)
Suction Capacity 86.3 cm
3
/rev (5.27 in
3
/rev)
Working Pressure Refer to Pressure Testing (Section E 4-1)
Working Flow TBA
Reduction Gear Ratio 39 : 1
Parking Brake
Brake Torque 26 kgf/m (188 lbf ft) including reduction gear
Brake Pressure Release > 10 kgf/cm
2
(142 lbf/in
2
)
Brake Valve Pressure Relief TBA
Dry Weight 165 kg (364 lb)
Boom Ram
Cylinder Inside Diameter 100 mm (3.94 in)
Rod Diameter 75 mm (2.95 in)
Max Contracted Length 1561 mm (61.46 in)
Stroke 1081 mm (42.56 in)
Dry Weight 116 kg (256 lb)
Dipper Ram
Cylinder Inside Diameter 115 mm (4.53 in)
Rod Diameter 80 mm (3.15 in)
Max Contracted Length 1714 mm (67.48 in)
Stroke 1205 mm (47.44 in)
Dry Weight 160 kg (353 lb)
Bucket Ram
Cylinder Inside Diameter 95 mm (3.74 in)
Rod Diameter 70 mm (2.76 in)
Max Contracted Length 1422 mm (55.99 in)
Stroke 924 mm (36.38 in)
Dry Weight 97 kg (214 lb)
1 - 2
Section E Hydraulics
9803/6410
Section E
1 - 2
Issue 2*
Technical Data (JS130)
