Travel Equipment
Motor Fixed displacement piston motor (automatic 2-speed change)
Suction Capacity 104.8 cm
3
/rev (6.39 in
3
/rev)
Working Pressure Refer to Pressure Testing (Section E 4-1)
Working Flow TBA
Reduction Gear Ratio 48 : 1
Parking Brake
Brake Torque 26 kgf/m (188 lbf ft) including reduction gear
Brake Pressure Release > 11 kgf/cm
2
(156 lbf/in
2
)
Brake valve pressure relief TBA
Dry Weight 225 kg (496 lb)
Boom Rams
Cylinder Inside Diameter 115 mm (4.53 in)
Rod Diameter 80 mm (3.15 in)
Max Contracted Length 1689 mm (66.65 in)
Stroke 1184 mm (46.61 in)
Dry Weight 157 kg (346 lb)
Dipper Ram
Cylinder Inside Diameter 125 mm (4.92 in)
Rod Diameter 90 mm (3.54 in)
Max Contracted Length 1875 mm (73.82 in)
Stroke 1335 mm (52.56 in)
Dry Weight 210 kg (463 lb)
Bucket Ram
Cylinder Inside Diameter 105 mm (4.13 in)
Rod Diameter 75 mm (2.95 in)
Max Contracted Length 1057 mm (59.33 in)
Stroke 997 mm (39.25 in)
Dry Weight 117 kg (258 lb)
1 - 4
Section E Hydraulics
9803/6410
Section E
1 - 4
Issue 2*
Technical Data (JS160)
