41 - 1
Dismantling and Assembly
Notes:
1 All parts are precision made and require the utmost
care when being handled.
2 During dismantling, do not use excessive force to
separate components which could cause scratches or
burrs on bearing surfaces. Failure to observe this
instruction will cause oil leaks leading to poor
performance.
3 Label all parts during dismantling, to ensure correct
assembly.
4 Storing the valve when dismantled could cause rusting
of parts. Ensure they are suitably protected by anti-rust
treatment.
5 During assembly, ensure all parts are clean and free
from burrs and scratches. Remove minor damage by
lapping.
6 Renew all ‘O’-rings, seals and back-up rings. Take care
to install seals the correct way around.
7 During assembly apply hydraulic oil to ‘O’-rings and
seals.
8 Ensure all screws and bolts are tightened to the torque
settings given.
Dismantling
Details of the service tools used in the dismantling and
assembly procedures are given in Service Tools, Section 1.
Note: For part number identification for the main valve
assembly, see illustration on page 40 - 2.
1 Push down upper section of gaiter 19 and remove roll
pin 20.
2 Remove control handle from mounting knuckle 23.
Note: Take care when removing handle to avoid damage to
wiring loom and switches.
3 Remove gaiter 19 from valve housing.
4 Slacken locknut 22 and remove mounting knuckle 23.
5 Slacken and remove joint nut 24 and rocker plate 25.
6 Using a jig, slacken and unscrew knuckle joint 26,
releasing retaining plate 18.
Note: Ensure retaining plate moves freely to prevent sudden
release due to spring pressure beneath.
Section E Hydraulics
9803/6410
Section E
41 - 1
Issue 1
Remote Control Valve (Services)
