Dismantling (cont’d)
4
Remove rear flange
101
from spindle
2
.
5
Remove two plugs
124
from rear flange
101
. Remove
‘O’-rings
155
from plugs
124
.
6
Remove two springs
128
, two plungers
125
and spool
123
fr
om the rear flange. T
ake care to avoid damaging
the mating surfaces of spool and rear flange.
7
Remove the two plugs
126
from rear flange.
8 - 2
Section F
T
ransmission
9803/6410
Section F
8 - 2
Issue 1
T
raction Motor
470
472
