13 - 5
Assembly (cont’d)
7
Complete the installation of locking wires
B
by tapping
with a hammer
8
Fill the unit with oil (see
Fluids and Lubricants
, Section
3) and install plug
A
using an appropriate pipe thr
ead
sealant.
Section J
T
rack and Running Gear
9803/6410
Section J
13 - 5
Issue 1
Bottom Roller
B
B
A
529
531
