10 - 9
Section C Electrics
9803/6400
Section C
10 - 9
Issue 1
CAPs II Diagnostic system
SELECT MONITOR MODE CLOCK WINDOW Unit/
SWITCH (*1) WINDOW WINDOW INDICATION ITEM Indication
CH; 3 7 Wrong electrical contact CN2-10 Battery Level sensor 1
(digital Signal) CN2-3 Lever lock 2
CN2-8 Battery charge 3
CN2-2 Emergency shut down 4
CN2-7 Spare 5
CN2-1 Spare 6
CN2-13 Spare 7
CN3-9 S-mode switch 8
CN3-4 H-mode switch 9
CN3-8 L-mode switch 10
CN2-6 F-mode switch 11
CN2-12 Change switch 12
CN2-5 Pattern switch 13
CN2-11 Select switch 14
CN2-4 Reset switch 15
CN3-3 Hard/soft change switch 16
CN3-7 Spare 17
CN3-6 Warning switch 18
CN3-2 Auto-idle switch 19
CN3-5 Over heat switch (oil) 20
CN3-1 Over heat switch (Water) 21
CN4-9 Limit switch (throttle motor) 22
CN4-4 Travel 2 speed change switch 23
CN4-8 Buzzer stop switch 24
CN4-3 One touch idle switch 25
CN4-7 Lever lock switch 26
CN4-6 Swing lock switch 27
CN4-2 Spare 28
CN4-5 2 stage relief switch 29
CN5-13 Spare 30
CN5-12 Engine oil pressure switch 31
CN5-4 Horn switch 32
CN5-11 Spare 33
CN5-3 Spare 34
CN5-10 Spare 35
CN5-9 Spare 36
CN7-1 Air filter 37
CN7-4 Reserve tank switch 38
CN7-5 Engine oil filter 39
Channel 3: Service Text (continued)
