JCM TBV Series User Manual

Part No. 960-100941R_Rev. A © 2016 JCM American Corporation
9
October, 2016 JCM® Training Overview TBV Transaction Based Validator
Table 8 TBV Sensor/Roller Types and Cleaning Methods
Symbol Sensor/Roller Type Cleaning Method
1 Transport Entrance Sensor Prism
Wipe clean using a soft, slightly
damp, lint-free Microfiber cloth*
* Wipe and clean all Rollers and the GREEN Colored Belts shown in Figure 3 using a soft, lint-free Microfiber cloth.
2 Centering Sensor
3 Side Sensor
4 Transport Entrance Sensor
5 Centering Sensor Prism
6 Bar Sensor
7 Box Near Full Sensor
8 Box Full Sensor
9 Feed Out Sensor Prism
10 UV Sensor
11 Magnetic Sensor
12 Feed Out Sensor
13 Pusher Plate Home Position Sensor
14 Box Lock Sensor
15 ICB
16 Pusher Mechanism Home Position Sensor
17 Box Sensor
18 Box Feed Out Sensor
19 Line Sensor
20 UV Sensor
21 BNF Reject Sensor
22 BNF Assignation Sensor
23 BNF Entrance Sensor
24 Pusher Plate Home Position Sensor Prism
25 ICB
26 Box Sensor Prism
27 Box Feed Out Sensor Prism
28 Pusher Mechanism Home Position Sensor Prism
29 Box Near Full Sensor Prism
30 Box Full Sensor Prism
31 Cash Box Lock Sensor Prism
32 Retard Roller
Wipe clean using a damp, lint-
free Microfiber cloth
†
† When cleaning the Retard Roller, Pick Up Roller, and Feed Roller, use a lint-free Microfiber cloth slightly dampened
with water.
33 Pick Up Roller
34 Feed Roller
NOTE: If Sensor Lenses or Prisms become exposed to water, wipe them dry
IMMEDIATELY using a soft, dry lint-free Microfiber cloth. Then allow them to air
dry for a sufficient amount of time to allow maximum evaporation.
