JCM VEGA Series User Manual

P/N 960-100189RA_Rev. A {EDP #148850} © 2009, Japan CashMachine Co., Limited
7-8
Section 7 VEGA™ Series BankNote Validator Exploded Views and Parts Lists
239 147148 900-200431R TMF Spacer 1 without Magnetic Sensor
240 003598 181-260006R
M2.6x6 Pan Head Screw With
W
asher 3M
4
241 061070 186-260005R
2.6x5 Phillips, Self Tightening,
Binding
3M Screw (Black)
2 without Magnetic Sensor
242 104081 186-266000RA
2.6x6 Phillips, Self Tightening,
Binding 3M Screw (Black)
9 without Magnetic Sensor
11 with Magnetic Sensor
243 140511 300-200154R Sensor Board 1
244 146118 186-266000R
2.6x6 Flathead, Phillips, Self
T
ightening 3M Screw (Black)
3
245 148625 300-100636R MAG Circuit Board 1 with Magnetic Sensor
246 148827 900-101169R TMF Rubber 1 with Magnetic Sensor
247
148868 400-100667R MAG Harness (12V) 1 with Magnetic Sensor
N/A 400-100668R MAG Harness (24V) 1 with Magnetic Sensor
Table 7-3 Lower VEGA Transport Unit Parts List (Continued)
Ref N
o
.EDP N
o
.JAC N
o
.
Description Qty. Remark
