JCM VEGA Series User Manual

P/N 960-100189RA_Rev. A {EDP #148850} © 2009, Japan CashMachine Co., Limited
7-13
Exploded Views and Parts Lists VEGA™ Series BankNote Validator Section 7
439 144612 200-200788R Set Pin 8 6
440 144810 900-200346R Stacker Belt 2
441 144841 900-200347R Ø5x9x0.4 Poly V
inyl Slider 3
442 000900 192-051008R Ø5x10x0.8 Plain Washer 1
443 110909 900-101014RA Prism C 1
444 091516 200-100984R Ø3 E-Ring 14
445 135327 200-100984R Thumb Knob A 1
446 135328 900-200423R Thumb Knob B 1
447 135329 900-200424R Thumb Knob Nut 1
448 135330 900-200425R Thumb Knob Cam 1
449 144607 900-200426R Pinch Roller 2
450 104081 186-266000R
2.6x6 Phillips, Self Tightening,
Bindi
ng 3M Screw (Black)
2
451 146118 171-266000R
2.6x6 Flathead, Phillips, Self
T
ightening 3M Screw
1
452 095878 200-200749R Ø3x15 Parallel Pin Sustainer (Hard) 2
453 144840 171-268000R
2.6x8 Phillips, Self Tightening,
Bindi
ng 3M Screw (Black)
12
454 127711 900-101180R IQ P-Box Handle (Large) 1
455 127712 900-101181R IQ P-Box Handle Bracket (Large) 2
Table 7-5 VEGA Cash Box Unit Parts List (Continued)
Ref N
o
.EDP N
o
. JAC N
o
.
Description Qty. Remark
