Appendix A VEGA™ SeriesBankNote Validator Troubleshooting
Yellow
3
(120)
Green
3
(120)
Banknote Length
Problem
Short Banknote length problem: While waiting for
Validation Sensor detection, the Intake
Sensor detected “no-bill” present. Or, while transporting Banknotes, the Escrow Sensor
waited for Banknote insertion detection and the Intake Sensor detected a “no-bill” present
condition.
Long Length problem: Inserted a Banknote having a length greater than 165mm.
[Solution] Check that the following parts are properly assembled and/or harness connected,
a
nd clean all of the Sensors.
Intake Sensor: SUB Board LED2 & LED3 & LED4 & L
ED5, CPU Board L57PT & R57PT & L72PT
& R72PT.
If the error is not resolved, change the above related part.
Blue
3
(120)
Double
Banknotes
The Validation Sensor’s transiency level is less than the accepted value. Dirt, stickers, or
foreign objects may be on the Banknote.
[Solution] Confirm the B
anknotes’ condition.
If the error is not resolved, perform a sensor calibration.
Yellow
3
(120)
Red
Cash Box Seating
Problem
Cash Box Sensors detect a Banknote remaining in path.
[Solution] Check that the following parts are properly assembled and/or harness connected,
a
nd clean all of the Sensors.
Cash Box Sensor: SUB Sensor Board (Upper) LED3 &
PS3 & CN1, SUB Board CN6 & CN8,
CPU Board CN7.
If the error is not resolved, change the above related part.
Blue
Red
3
(120)
Yellow
3
(120)
White
Pusher
M
echanism
Problem
Pusher Mechanism Home Sensor detects that the Pusher Mechanism is not presently at the
Home e
nd position.
[Solution] Check that the following parts are properly assembled and/or harness connected,
a
nd clean all of the Sensors.
Pusher Mechanism Home Position Sensor: SUB Board LED7
& PT2 & CN8, CPU Board CN8.
If the error is not resolved, change the above related part.
Purple
White
3
(120)
Table A-3 Reject Codes (Continued)
on-line off-line
Error Causes and Solutions
Color
Flashes
(msec)
Color
Flashes
(msec)
