JDE EXCELLENCE COMPACT BLACK - Dimensions

8
User manual
2- Technical specications
2.2 Dimensions
Position Description Millimeters
A Dispenser width 390
B Dispenser depth 426
C Dispenser depth with door open 500
D Dispenser height 562
E Dispenser height with door open 755
F Distance from top of dispenser to front of open door 193
G Clearance with drip tray in place 130
H Clearance with drip tray removed 165
A
C
B
D E
F
G H
