Jelrus Infinity M-30 - Program and Operate: Two Stage

OPERATION
PROGRAM AND OPERATE - TWO STAGE PROGRAM (Figure1)
10
1FollowOneStageProgram,Steps1-6
2PressENTER/REVIEWSTAGE1lightturnsoff,STAGE2andHEATRATElightsturnonMain 
DisplayshowsfourheatratechoicesChooseone:
 ASelectheatratebetween1°F-30°F/min(1°C-17°C/min)using
 BSelect"FULL"toprogrammaximumheatrate
 CSelect"COOL"toprogramthefurnacetocooltoaselectedtemperature
 DSelect"NO"toturnofSTAGE2,3and4ThiswillresultinaOneStageProgram
NOTE: The HEAT RATE cannot be programmed to "COOL" in STAGE 1 - only in STAGE 2,
3 or 4.
3PressENTER/REVIEWHEATRATElightturnsoffandTEMPlightturnsonEnterforthe 
temperaturerequired:heatingtemperatureuptoamaximumof2012°F(1100°C)orcooling
temperaturedowntoaminimumof100°F(38°C)
4PressENTER/REVIEWTEMPlightturnsoffandHOLDTIMElightturnsonEntertoprogramthe
timeneededtoholdattheabovetemperature(0-4hrs)
5Fortwostages,thefurnacemustbeprogrammednottouseSTAGE3or4Followthesesteps:
 AAftercompletingStep4,pressENTER/REVIEWSTAGE2lightturnsoff,STAGE3andHEAT 

RATElightsturnon
 BPressMainDisplayshows“5,4,3,2,1,COOL,NO”Select“NO”toprogramthe
 furnacenottouseSTAGE3or4
6Allnecessaryinformationforthisprogramisnowentered
7Toruntheprogramimmediately,pressSTART/STOP
8Todelaythestartoftheprogramtobereadytocastatthepre-settime(seeOneStageProgram,
Step3),pressNIGHTTIME(DELAYSTART)
NOTE: If NIGHT TIME (DELAY START) is pressed while a program is running, the time
remaining for completion of the program will appear on the Main Display for 5
seconds.







