Jelrus Infinity M-30 - Installation Guide

UNPACK AND SET-UP
INSTALLATION
7
1 UnpackthecontentsoftheboxRemovethefollowingmaterials:
 AVentTube-Removefrombubblewrapandinsertinholeontopoffurnace
 BCalibrationTableKit-Removeplasticbagcontainingtwotabletsandsaveforfutureuse
 CBurnoutTray-Removetray(s)frombubblewrapandinstallonthefloorofthechamber
2 Placethefurnaceinpositionallowingaminimumof2inches(5cm)ofairspaceonallsides
3 PlugthepowercordintoawallreceptacleOn220/230Vand240furnaces,firstconnectthepowercord
 totheIECreceptaclelocatedontherearofthefurnaceAseparateelectricalcircuitisrecommended
 Thevoltageratingofyourfurnaceisontheserialnumberplate
4 Thefurnaceisnowreadyforoperation
CAUTIONS:
Do not install closer than 2" (5cm) from any combustible material. DO NOT BLOCK VENT
HOLE ON TOP OF THE FURNACE. Hot gases are vented through this hole.
TO SET TEMPERATURE SCALE (Figure1)
115Vfurnacesarepre-setindegreesFahrenheit
100V,220/230Vand240Vfurnacesarepre-setindegreesCelsius
1 Turnthepowerswitchon(Ifthefurnaceisalreadyon,besureitisintheidlemode-noprogramis
 running)ThechambertemperatureappearsontheMainDisplayandthe°Cor°Flightgoeson
2Press atthesametimeThedegreelightswitchestotheoppositetemperaturescale


