Jelrus Infinity M-30 - Field Service Procedures; Replace Heating Plates

1 Removethebackpanelofthefurnace
2 Removethenutswhichholdtheheatingplatewirestothepowerterminalsandstraightentheheating
 platewires(Figure4)
3 OpenthefurnacedoorandfindthetwoceramicsectionsatthefrontofthefurnacechamberHoldthe
 furnacedoorpartiallyopenwhileremovingtheceramicsectionsTheyarenotreadilyremovedwhenthe
 doorisfullyopenRemovetheright-handceramicsectionbyliftingitupwarduntilthebottomofthesection
 clearsthesheetmetalhousingPullthebottomoftheceramicsectionout,thenpullitdownsotheupper
 halfclearsthesheetmetalhousingRemovetheleft-handceramicplateinthesameway
4 Removethefloorplate,thencarefullyslidethetwosideheatingplatesoutthefrontofthefurnaceThetwo
 rearheatingplatesonInfinityL-30maynowberemoved
5Checktheconditionofthefillerstripinsulationinthespacetotheleftandrightoftheceramicfront
 sectionsReplaceifrequired*
6Checktheconditionofthefloorplatewhichprovidesinsulationandservesasaspacerbetweenthebottom
 endsoftheheatingplatesReplaceifrequired*
7ToinstallthenewheatingplatesreversetheprocedurePushtheceramicheatingplatesbackintoplaceon
 therearinsulatingpanelWhenreconnectingtheheatingplatewiresattherearofthefurnace,besureto
 replaceallhardwareinitsoriginalposition(Figure4)Tightenallconnections
 *ReplacementPart:FloorPlatew/FillerStripInsulation
InfinityM-30:PN33980;InfinityL-30:PN33981
FIELD SERVICE
REPLACEMENT OF HEATING PLATES
REPLACEMENTPARTNUMBERS
21
 100V 115V 220/230V 240V
M-30 (Setof2) 18907 33915 33916 33916
   
L-30
Setof2SidePlates 27957 33918 27957 33918
Setof2RearPlates 27956 33917 27956 33917
