Jensen CAR10 - Installation and Wiring Guide

5
CAR10 PREPARATION
Before You Start
• Disconnect negative battery terminal. Consult a qualified technician for instructions.
• Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it
would be subject to dust, dirt or excessive vibration.
Preparation
LEFT/RIGHTVIEWOFSCREEN
TRIM RING
MOUNTING SCREWS
M5.0x6.0mm M5.0x5.0mmM2.6x6.0mm
MOUNTING BRACKET
* Use 2 or 3 screws to affix the monitor to the bracket.
