Jensen VM9215BT - Bluetooth User Interface

67
VM9215BT
Bluetooth User Interface
The on-screen indicators and touch key areas for Bluetooth® functions are outlined
below.
1. BT icon: Touch to view the SOURCE MENU and select a new playback source.
2. Equalizer setting indicator: Displays the current equalizer preset setting.
3. EQ icon: Touch for quick access to Equalizer level settings.
4. Clock: Displays the time as entered by the user in the settings menu.
5. / indicator: Indicates whether the unit is disconnected/connected with
a Bluetooth®device.
6. Pair icon: Touch to initiate the pairing process with a Bluetooth®device.
7. Options icon: Touch to con gure Bluetooth® parameters and options. Refer to
the Options screen for further details.
8. BT Audio icon: Touch to access the Bluetooth® music function.
9. Phone icon: Touch to access the phone call menu.
10. icon: Touch to return to a previous menu.
