VM9726BT

External Devices

External peripheral devices, including a game console, camcorder, navigation unit,

iPod®, Zune, etc. can be connected to this unit via RCA output using an A/V Media

Adapter Cable (not included).

3.5mm A/V Cable (not included)

V ideo

Left Audio

Right Audio

Ground

Cover Not Shown

Connect the external device to the A/V Media Adapter Cable and then plug the

cable into the A/V INPUT connector on the front of the radio. Select “AUX IN” mode

to access auxiliary devices. You cannot directly control external devices connected

to the A/V INPUT. For information regarding the use of USB devices, see “Inserting

a USB Device or SD Card”.

Volume Adjustment

Volume Increase/Decrease

To increase or decrease the volume level, turn the rotary encoder on the front

panel. When the volume level reaches “0” or “50”, a beep sounds, indicating that

the adjustment limit has been reached. The TFT screen displays the volume level

for 3 seconds.

Programmable Turn-On Volume

This feature allows the user to select a turn-on volume setting regardless of the

volume setting prior to turning the unit o. To program a specic turn-on volume

level, turn the rotary encoder to adjust the volume to the desired turn-on volume.

Push and hold the rotary encoder while the speaker icon and level indication

is displayed on the screen. The unit will beep to conrm your turn-on volume

setting.
